PCoIP® Solutions

Leostream with PCoIP Products and Cloud Solutions

Leostream works seamlessly with HP Anyware and PCoIP Remote Workstation Cards, providing high-quality graphics for applications running in the datacenter or cloud. The Leostream Connection Broker allows IT to pool, assign, and manage all PCoIP devices in their organization from a single interface.

Resources-Tutorials

PCoIP Zero Clients

Leverage secure PCoIP Zero Clients with native access to Leostream.

Product-Features-Hybrid-Cloud

HP Anyware

Build a hybrid solution using Leostream to manage connections to VMs running PCoIP Agents.

Product-Features-Provisioning

Remote Workstation Cards

Connect to Windows, Linux or macOS with a PCoIP Remote Workstation Card.

Resources-Infographic

Maximize Workstation ROI

Optimize shared workstation usage by monitoring idle time and automating disconnects and log outs.

Remote Access Options for Leostream with PCoIP Technology

Organizations that leverage the PCoIP display protocol have a number of options when it comes to providing remote access for their users. The configuration depends on the type of client the user needs to connect from and the type of remote resource they need to connect to.

Are you using Cloud Access Software?

A combined Leostream and HP Anyware deployment is depicted in the following figure.

This combination provides remote access from PCoIP Zero client, software client, or mobile client to virtual or cloud-hosted machines running any version of the PCoIP Agent.

NOTE: The PCoIP Connection Manager and Security Gateway is not the same as the HP Anyware Manager or Anyware Connector. Contact HP for your PCM/SG for Leostream.

Do you have Remote Workstation Cards?

If your users have PCoIP Zero clients and your desktops/workstations have installed or external PCoIP Remote Workstation Cards, you can use the Leostream Gateway to provide remote access, as depicted in the following figure.

This combination provides remote access for users with PCoIP Zero clients to workstations with installed PCoIP Remote Workstation Cards.

NOTE: To support this architecture, do not install the PCoIP Remote Workstation Card Agent on the operating system connected to the PCoIP Remote Workstation Card.

What if I want to use a Leostream Client?

To launch a PCoIP connection, you must log into Leostream using a PCoIP client or the Leostream Web client. Depending on which type of client you use, you can connect to different types of remote resources.

Summary WHEN USING A PCOIP CLIENT

The following information assumes you require a gateway to remote the PCoIP traffic. If your users are located in the same network as the desktops they are trying to connect to, this table does not apply, nor does it apply if you establish a VPN connection from your user’s client to your desktops.

I’m logging in fromAnd connecting toSo which Gateway do I use?
PCoIP Software client

Virtual, Cloud, or physical desktop running the PCoIP  Agent

PCoIP Security Gateway
PCoIP Zero clientVirtual, Cloud, or physical desktop running the PCoIP AgentPCoIP Security Gateway
PCoIP Mobile ClientVirtual, Cloud, or physical desktop running the PCoIP AgentPCoIP Security Gateway
PCoIP Software clientA workstation with an install Remote Workstation Card and running the PCoIP Remote Workstation Card AgentNot supported for remote access
PCoIP Zero clientA workstation with an install Remote Workstation Card and running the PCoIP Remote Workstation Card AgentSee below for a supported option
PCoIP Mobile ClientA workstation with an install Remote Workstation Card and running the PCoIP Remote Workstation Card AgentNot supported for remote access
Leostream Connect launching the PCoIP Software client (Windows, only)A workstation with an install Remote Workstation Card without the Remote Workstation Card AgentThe Leostream Gateway
PCoIP Zero clientA workstation with an install Remote Workstation Card without the Remote Workstation Card AgentThe Leostream Gateway
PCoIP Mobile ClientA workstation with an install Remote Workstation Card without the Remote Workstation Card AgentNot supported for remote access

Ready to get Started?

Discover how Leostream can optimize your PCoIP  environments.
